| Type: | Energy Type | Size: | 1/2AA |
|---|---|---|---|
| Nominal Capacity: | 1200mAh（at 0.5mA, +20°C/2.0V Cut Off) | Nominal Voltage: | 3.6V |
| OCV: | 3.66V | Cut-off Voltage: | 2.0V |
| Operating Temperature: | -55°C~+85°C | Dimension: | 14.5(D)*25.2(H)mm |
| Weight: | About 9g | Shelf Life: | ≥10 Years |
| Applications: | Intelligent And Instrument Area, Remote/Wireless, Intelligent Fire Control System | ||
| Highlight: | lithium thionyl chloride cell,li socl2 lithium battery |
||
| Model | ER14250 |
| Type | Energy Type |
| Size | 1/2AA |
| Nominal Capacity | 1200mAh(at 0.5mA, +20°C/2.0V cut off) |
| Nominal Voltage | 3.6V |
| OCV | 3.66V |
| Cut-off Voltage | 2.0V |
| Dimension | 14.5(D)*25.2(H)mm |
| Weight | 9g |
| Max. Continuous Current | 25mA |
| Max. Pulse Current | 50mA |
| Operating Temperature |
-55°C~+85°C
|
| Storage Temperature | Max.30°C |
| Shelf Life | ≥10 years |
| Self Discharge Rate | ≤1% |
| Compatibility |
Can replace 1/2AA size batteries
Tadiran TL-5902, TL-2150, TL-5151, TL-5902, TL-5101, TL-5111
Saft LS-14250, LS-14250c
Toshiba ER3v
Sonnenschein SL-350/S, SL-750/S, SL-150/S
pmd 14250, sx 14250, tt 14250, AMD 14250, tx 14250, ca 14250, alpha 14250, km 14250, BM 14250, IP 14250, ex 14250, qm 14250, gx 14250, ww 14250, dx 14250, sm 14250, bk 14250, er14250h
|
Discharge Curves at(25℃)
Capacity-current Curves
Operating Voltage-temperature Curves
