Product Details
Place of Origin: Wuhan
Brand Name: FBATTERY
Certification: CE UL ISO9001 ISO14001
Model Number: 6GFMJ-38
Payment & Shipping Terms
Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: Carton and Wooden Pallet
Delivery Time: 30DAYS
Payment Terms: T/T L/C, D/A, D/P
Supply Ability: 10000PCS/30Days
Type: |
Deep Cycle Hybrid Gel Battery 12 Volt 38AH |
Nominal Voltage: |
12 Volt |
Rated Capacity: |
38AH |
Battery Case: |
ABS |
Battery Designed Life: |
12 Years |
Approx Weight: |
13.2KG |
Screw Hole Size: |
M6 |
Application: |
Photovoltaic System, Hybrid Power System, Power Storage |
Dimension: |
L197*W165*H170mm |
Type: |
Deep Cycle Hybrid Gel Battery 12 Volt 38AH |
Nominal Voltage: |
12 Volt |
Rated Capacity: |
38AH |
Battery Case: |
ABS |
Battery Designed Life: |
12 Years |
Approx Weight: |
13.2KG |
Screw Hole Size: |
M6 |
Application: |
Photovoltaic System, Hybrid Power System, Power Storage |
Dimension: |
L197*W165*H170mm |
Power Storage Deep Cycle Hybrid Gel Battery 12 Volt 38AH Copper Terminal
Deep Cycle Hybrid Gel Battery 12 Volt 38AH advantage
♦ Safety seal ,Deflating system ,Simple maintenance ,long lasting ,Stable quality and high reliability
♦ Gelled electrolyte made by mixing sulfuric acid with silica fume.
♦ The electrolyte is gel like ,immobile and does not leak ,enabling uniform reaction of each part of the plate .
♦ High rate discharge performance due to tight assembly technology
♦ Strong heat dissipation and wide operating temperature range
♦ Avoid acid mist being separated out , environment friendliness
♦ Efficient venting system release excessive gas automatically
Product Structure and Working Principle
Positive plate : Thick high Sn low Ca grid with high density paste
Negative plate : Over designed capacity to overcome sulphation in low SOC Separator :Advanced AGM
separator
Electrolyte : Dilute high purity sulphuric acid with nano gel Battery container and cover :ABS
Pillar seal : 100% factory tested, proven two layers epoxy resin seal Relief valve : Complete with
integrated flame arrestor
Specification
|
Type |
Gel Deep Cycle Battery |
|
Nominal Voltage |
12V |
|
Rated Capacity |
38Ah@10HR-rate (to 1.80Vpc) |
|
Approx Dimensions(mm) (Length×Width×Height) |
L197*W165*H170mm |
|
Battery designed life |
12 years |
|
Approx Weight(kg) |
13.2kg |
|
Applicable Temperature |
-40℃～60℃ |
|
Optimum Temperature |
20℃～25℃ |
|
Self-discharge |
Self-discharge rate＜0.1% per day ( 20℃ ) |
|
Materials for Battery Containers and Covers |
ABS |
|
Terminal Type (mm) |
Female Copper lnsert M6 (torgue:6～ 8N.m) |
|
Internal Resistance |
0.0095Ohm (fully charged @ 25°C)
|
|
Max. Charge Current |
9.5A |
|
Max. Discharge Current (5S)
|
500 A
|
|
Short Circuit Current
|
1250 A
|
Constant Currant Discharge Ratings-amperes at 25°C
Constant Power Discharge Ratings-watts at 25°C
Application Fields
This series is suit for energy storage for renewable energies such as PV, wing turbine power systems and CATV.
