Product Details
Place of Origin: Wuhan
Certification: CE, ROHS, UN38.3
Model Number: LSC1550
Payment & Shipping Terms
Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: Carton
Delivery Time: 20 Days
Payment Terms: L/C, D/A, D/P, T/T
Supply Ability: 10000PCS/30Days
Product System: |
Lithium Supercapacitor Cell |
Nominal Capacity(3.67V): |
220mAh |
Nominal Voltage: |
4.0Volt |
Internal Resistance: |
≤150mΩ |
Operating Temperature: |
﹣40℃～+85℃ |
Weight: |
About 21g |
Applications: |
Remote/Wireless, Intelligent Fire Control System |
Product System: |
Lithium Supercapacitor Cell |
Nominal Capacity(3.67V): |
220mAh |
Nominal Voltage: |
4.0Volt |
Internal Resistance: |
≤150mΩ |
Operating Temperature: |
﹣40℃～+85℃ |
Weight: |
About 21g |
Applications: |
Remote/Wireless, Intelligent Fire Control System |
4.0V 220mAh Sealed Lithium Supercapacitor Cell Energy Storage
Lithium Supercapacitor Cell Features
The Lithium super capacitor is a composite super-capacitor fabricated by hybrid lithium ion secondary batteries electrode materials, including graphite, lithium cobalt oxide, lithium iron phosphate, and metal oxides, with an activated porous carbon with high specific surface area. Due to the addition of lithium-ion batteries electrode materials, the energy storage mechanism of the composite super-capacitors is no longer the traditional nonaradic double-layer charge storage mechanism.
Lithium Supercapacitor Cell Performance Data
| Product System | Lithium Supercapacitor Cell |
| Model | LSC1550 |
| Nominal Capacity(4.0V) | 220mAh |
| Nominal Voltage | 4.0V |
| Internal Insistance | ≤150mΩ |
| Max. Continuous Discharge Current | 2000mA |
| Max. Pluse Current | 5000mA |
| Max. Charge Current | 1000mA |
| Max. Charge Voltage | 4.0V |
| Discharge End Voltage | 2.5V |
| Operating emperature | ﹣40℃～+85℃ |
| Weight | About 21g |
Lithium Supercapacitor Cell Characteristic Curve
Discharge Curve at 25℃
Advantages
1. It can realize instantaneous large current discharge
2. Long-life energy storage device
3. Fully sealed structure and wide working tem perature range,
4. Suitable for long-term use in harsh environments.
