Product Details
Place of Origin: Wuhan
Brand Name: FBATTERY
Certification: CE, ROHS, UN38.3
Model Number: ER14505M
Payment & Shipping Terms
Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: Carton
Delivery Time: 20 Days
Payment Terms: L/C, D/A, D/P, T/T
Supply Ability: 10000PCS/30Days
Product System: |
Lithium Thionyl Chloride Battery |
Nominal Capacity: |
2200mAh(1mA-2.0v-25℃) |
Nominal Voltage: |
3.6V |
Operating Temperature: |
-60℃～+85℃ |
Weight: |
21g |
Applications: |
Intelligent And Instrument Area, Remote/Wireless, Intelligent Fire Control System |
Product System: |
Lithium Thionyl Chloride Battery |
Nominal Capacity: |
2200mAh(1mA-2.0v-25℃) |
Nominal Voltage: |
3.6V |
Operating Temperature: |
-60℃～+85℃ |
Weight: |
21g |
Applications: |
Intelligent And Instrument Area, Remote/Wireless, Intelligent Fire Control System |
| Model | ER14505M |
| Type | Spiral Type |
| Size | AA |
| Nominal Capacity | 2200mAh(at 1mA, +25°C/2.0V cut off) |
| Nominal Voltage | 3.6V |
| OCV | 3.66V |
| Cut-off Voltage | 2.0V |
| Dimension | 14.5(D)*50.5(H)mm |
| Weight | 19g |
| Max. Continuous Current | 500mA |
| Max. Pulse Current | 1000mA |
| Operating Temperature | -60°C~+85°C |
| Storage Temperature | Max.30°C |
| Shelf Life | ≥10 years |
| Self Discharge Rate | ≤1% |
