High Power Density LiFePO4 Lithium Iron Phosphate Battery 12V 80Ah Replacement for Lead Acid

Name: High Power Density LiFePO4 Lithium Iron Phosphate Battery 12V 80Ah Replacement for Lead Acid
Brand: Wuhan Future Intepower Co., Ltd.
SKU: FB-1280
Availability: InStock

Product Details

Place of Origin: China

Brand Name: FBATTERY

Certification: CE,UL,ROHS

Model Number: FB-1280

Payment & Shipping Terms

Minimum Order Quantity: Negotiable

Price: Negotiable

Packaging Details: Carton

Delivery Time: 20Days

Payment Terms: L/C,D/A,D/P,T/T in advance

Supply Ability: 10000PCS/30Days

Get Best Price

Product Details

Product Description

Highlight:
                                                                                                                                                                                                                                                            Lead Acid Battery 12V 80Ah, Lead Acid Battery 8.6kg


Cell Type:	LiFePO₄	Rating Voltage:	12V
Capacity:	80Ah	Charge Voltage:	14.6V±0.05V
Impedance:	15mΩ（Max）	Size:	LWH=260167210mm
Operating Temperature:	Charging 0~45℃	Storage Temperature:	-10℃-40℃ Recommend（25±5℃）
Weight Approx:	8.6kg

Cell Type:	LiFePO₄
Rating Voltage:	12V
Capacity:	80Ah
Charge Voltage:	14.6V±0.05V
Impedance:	15mΩ（Max）
Size:	LWH=260167210mm
Operating Temperature:	Charging 0~45℃
Storage Temperature:	-10℃-40℃ Recommend（25±5℃）
Weight Approx:	8.6kg

High Power Density LiFePO4 Lithium Iron Phosphate Battery 12V 80Ah Replacement for Lead Acid

High Power Density LiFePO4 Lithium Battery Replacement Lead Acid 12V 80Ah Powerful

High Power Density LiFePO4 Lithium Battery designed as a direct replacement for lead acid batteries, offering superior performance and reliability.

Specifications

No	Item	Parameter	Remark
1	Rating Voltage	12.8V
2	Capacity	80Ah	0.5C discharge after full charge
	Minimum Capacity	78AH
3	Charge Voltage	14.6V±0.05V
4	Impedance	15mΩ(Max)
5	Charging Mode	C.C/C.V.	Constant Current / Constant Voltage
6	Charging Method	Standard Charging	Charging Current 12A
	Fast Charging	Charging Current 40A
7	Charging Time	Standard Charging	7.5 Hours
	Fast Charging	2.6 Hours
9	Overcharge Voltage	3.65±0.05V
10	Over Discharge Cut Off Voltage	2.2V±0.1V
11	Over Current	200-300A
12	Short Circuit
13	Operating Consumption Current	50uA(MAX)
14	Operating Temperature	Charging: 0~45℃ Discharging: -10~60℃
15	Storage Temperature	-10℃-40℃ Recommend(25±5℃)	Storage capacity should be 40%~50% full charge capacity
16	NTC Resistor	/
17	ESD Test	±4KV
18	Discharge current	≤80A
19	The factory voltage	12.8-13.6V	The open circuit state
20	Weight Approx	8.6KG

Storage Guidelines

The battery storage shall be in a clean, dry, and well-ventilated room at temperatures between -5℃ to 35℃. Keep batteries away from fire, heat sources, and corrosive elements.

Batteries should be charged every 3 months during storage. Follow the "first come, first use" principle for both stored cells in process and batteries in delivery.

The battery storage period is 24 months from warehouse entry. Batteries exceeding this period must undergo thorough inspection. Only applicable batteries can be dispatched to purchasers; inapplicable units shall be rechecked, and purchasers retain the right to dispose of defective batteries.
