Product Details
Place of Origin: Wuhan
Certification: CE UL ISO9001 ISO14001
Model Number: 6GFM-200
Payment & Shipping Terms
Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: Carton and Wooden Pallet
Delivery Time: 30DAYS
Payment Terms: T/T L/C,D/A,D/P
Supply Ability: 100000PCS/30Days
Type: |
Vrla Valve Regulated Lead Acid Battery |
Nominal Voltage: |
12Volt |
Nominal Capacity: |
200AH |
Dimension: |
L520mm X W240mm X H219mmxTH224mm |
Other Name: |
VRLA Rechargeable Battery |
Approx Weight: |
60KG |
Terminal Type: |
Female Copper Insert M8 (torque:10~12N.m) |
Container Material: |
ABS |
Usage: |
Fire & Security Systems |
Type: |
Vrla Valve Regulated Lead Acid Battery |
Nominal Voltage: |
12Volt |
Nominal Capacity: |
200AH |
Dimension: |
L520mm X W240mm X H219mmxTH224mm |
Other Name: |
VRLA Rechargeable Battery |
Approx Weight: |
60KG |
Terminal Type: |
Female Copper Insert M8 (torque:10~12N.m) |
Container Material: |
ABS |
Usage: |
Fire & Security Systems |
Sealed VRLA Valve Regulated Lead Acid Battery 12V 200AH Deep Cycle is designed for reliable performance in demanding applications.
By combining a newly developed corrosion resistance alloy and advanced curing process, we created a range of long life batteries - Duration range. The range features top termination and offers 10 years design life.
| Type | Valve Regulated Lead Acid Battery |
| Nominal Voltage | 12 Volt |
| Rated Capacity | 200Ah (10 Hr, 10.8V, 25℃) |
| Approx Dimensions (mm) | L520mm x W240mm x H219mm x TH224mm |
| Battery Designed Life | 10 years |
| Approx Weight | 60kg |
| Applicable Temperature | -40℃~60℃ |
| Optimum Temperature | 20℃~25℃ |
| Internal Resistance | Approx. 0.0003 Ohm (fully charged @ 20°C) |
| Max. Charge Current | 50A |
| Max. Discharge Current (5S) | 1000A |
| Short Circuit Current | 4000A |
| Self-discharge | Self-discharge rate <0.1% per day (20℃) |
| Materials for Battery Containers and Covers | ABS |
| Screw Hole Size (mm) | M8 |
| F.V/Time | 5min | 10min | 15min | 30min | 1h | 2h | 3h | 4h | 5h | 8h | 10h | 20h |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 1.60V | 525 | 400 | 340 | 221 | 134 | 78.5 | 56.7 | 45.2 | 37.6 | 25.7 | 21.2 | 11.4 |
| 1.67V | 468 | 368 | 321 | 211 | 130 | 77.2 | 56.0 | 44.6 | 37.1 | 25.3 | 20.9 | 11.2 |
| 1.70V | 418 | 335 | 303 | 203 | 127 | 76.1 | 55.3 | 44.1 | 36.8 | 25.1 | 20.7 | 10.9 |
| 1.75V | 363 | 311 | 281 | 196 | 125 | 74.8 | 54.5 | 43.6 | 36.4 | 24.7 | 20.4 | 10.7 |
| 1.80V | 321 | 283 | 262 | 187 | 121 | 73.2 | 53.4 | 42.6 | 35.5 | 24.1 | 20.0 | 10.5 |
| 1.85V | 275 | 254 | 239 | 177 | 115 | 70.4 | 51.7 | 41.4 | 34.6 | 23.6 | 19.5 | 10.3 |
| F.V/Time | 5min | 10min | 15min | 30min | 1h | 2h | 3h | 4h | 5h | 8h | 10h | 20h |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 1.60V | 923 | 718 | 621 | 408 | 249 | 133 | 96.3 | 77.1 | 64.5 | 44.5 | 36.9 | 19.9 |
| 1.67V | 835 | 669 | 589 | 392 | 244 | 131 | 95.8 | 76.5 | 64.1 | 44.1 | 36.6 | 19.6 |
| 1.70V | 754 | 614 | 562 | 380 | 240 | 130 | 95.3 | 76.3 | 64.0 | 43.9 | 36.4 | 19.3 |
| 1.75V | 664 | 577 | 527 | 370 | 237 | 129 | 94.6 | 76.1 | 63.7 | 43.7 | 36.2 | 19.1 |
| 1.80V | 595 | 530 | 496 | 357 | 232 | 128 | 93.6 | 75.0 | 62.7 | 43.0 | 35.8 | 18.9 |
| 1.85V | 518 | 483 | 457 | 340 | 224 | 124 | 91.3 | 73.5 | 61.7 | 42.3 | 35.0 | 18.5 |
12V series VRLA deep cycle batteries are produced through internationally advanced technology and modern equipment and designed by fully type performance test. The positive plate uses high-tin alloy grids with strong corrosion resistance. The float charging life of battery can reach more than 5 years.
Adopting dedicated ultra-fine glass fiber separators with high porosity and high wet-elasticity, combining with tight assembling technology, the battery has a high tolerance for super over-discharge. After 5 times of over-discharges which cause the short circuit, battery tolerance restoration can reach more than 95%.
Special gel electrolyte additives, curing process at high temperature and high humidity are employed to delay the softening of active material, therefore the deep cycle endurance is improved up to 50%, especially the anti-passivation (anti barrier layer) capacity of positive plates during reaction when batteries are used for small load and small current discharge.
Precise, quantitative, low temperature, vacuum acid filling method, advanced and environmentally friendly container formation technics ensures battery stable consistency.
